TFC-600DW-A | 600-gallon Aviation Fuel Trailer
This package features a Double Wall 600-gallon tank. It consists of a stainless-steel primary tank with internal baffles and a mild steel outer containment with powder coat finish. It is mounted to a 21K GVW triple-axle steel trailer, is DOT approved for use with JET-A, and can be towed on public highways when full.
Our standard aviation equipment packages are comprised of 100% aviation-grade components. Featuring the most trusted brands in the aviation industry, such as: Great Plains Industries, Facet, OPW, Continental Hose, and Hannay. We can customize the equipment packages to run off 12 volt DC, 115 volt AC, or a gasoline-powered pump.
| Tank Size | 600-gallons |
| Tank Thickness | 10 Gauge |
| DOT Status | Approved for JET-A |
| Axles | 3 @ 3,500 lbs each |
| Hubs | 5 x 4.5" |
| Tires | 15" Radial |
| Fuel Baffles | 2 |
| Trailer Frame | 4" C channel |
| GVWR | 7,000 lbs |
| LxWxH | 190" x 72" x 60" |
- Tank level gauge, leak gauge, lockable fill cap, 20” Betts hatch with vacuum/pressure vent
- Stainless Steel baffles to prevent fuel sloshing
- Powder coat paint with base coat primer
- Integrated fuel sump with spring close valve
- Hoses, piping, and fittings are aviation grade
- Ball valve installed to isolate the tank
- Custom hose lengths available 1” to 2” diameters
- Powered retractable hose reels in 12-volt and 115-volt
- Pump options: 12-volt, 115-volt, gas powered and diesel-powered
- TCS Certifiable and calibratable re-sale meters
- Piusi, TCS, and QT Pod fuel management and sales systems
- Refuel/defuel system. Great option that allows the pump to pull fuel out of a tank as well as dispense it. A Transfueler exclusive.
- Bottom fill with overfill prevention valve, stainless drop tube. Ball valve and Whittaker dry disconnect (Single Point) connector
- Spare Tire with mount - 15” or 16”
- Toolbox: 48” or 60”
- Locking steel enclosed cabinet; secures dispensing equipment
- Work lights LED - 12 volt or 115 volt
- Solar panel system 100 watt - Include mounting brackets, controller, panel, and wiring.
- Air compressor, electric or gas-powered
- Generator, diesel or gas-powered
- Fork Lift Pockets
- Spill Containment Kit
- Ladder
- Remote Tank Sensor
- Battery Upgrade
- Underwing (Single Point) Nozzle
- Differential Pressure Gauge
- Water Detection System
- Replacement Filters
- Deadman System
- Aluminum Mag Wheels
Watch the walkaround video
